Especificaciones técnicas
Frameset
CUADRO
FACT 11m carbon chassis and rear-end, Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, internal brake and dropper cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel
SWAT
SWAT 4.0 internal downtube storage
ABRAZADERA
Alloy, 38.6mm
Suspension
SUSPENSION TRASERA
FOX FLOAT Performance with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever w/ LSR adjustment, S1:210x52.5mm, S2-S6:210x55mm
HORQUILLA
FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm QR axle, 44mm offset, S1:140mm of travel, S2-S6:150mm of travel
Cockpit
POSTE DE ASIENTO
X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 125mm, S2: 150mm, S3: 170mm, S4-S6: 190mm
POSTE
Alloy Trail Stem, 35mm bar bore
PUÑOS
Specialized Trail Grips
ASIENTO
Bridge Comp, Hollow Cr-mo rails, S1-S2: 155mm, S3-S6: 143mm
MANUBRIO
Specialized, 6000 series alloy, 6-degree upsweep, 8-degree backsweep. S1-S2: 780 width, 20mm rise: S3-S4: 800 width, 30mm rise: S5-S6: 800 width, 40mm rise
Brakes
FRENO DELANTERO
SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 200mm
FRENO TRASERO
SRAM Maven Bronze, 4-piston caliper, hydraulic disc, S1-S2: 180mm, S3-S6: 200mm
Drivetrain
PALANCA DE CAMBIOS
SRAM AXS POD Controller
DESVIADOR TRASERO
SRAM S1000 Eagle Transmission Derailleur
CASSETTE
SRAM XS-1270 Transmission Cassette, 12spd, 10-52t
CADENA
SRAM GX Eagle Transmission Flattop Chain
PEDALIER
SRAM S1000 Crankset, 32T ring, Integrated Guard, 55mm Chainline, S1-S3:165mm, S4-S6: 170mm
EJE DE CENTRO
SRAM DUB, BSA 73mm Wide, Threaded
Wheels & Tires
LLANTAS
Specialized, hookless alloy, 30mm inner width, tubeless ready, Front: 29, Rear: S1-S2:27.5, S3- S6:29
MAZA DELANTERA
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
MAZA TRASERA
Alloy, sealed cartridge bearings, 12x148mm thru-axle, 28h
RAYOS
DT Swiss Industry
LLANTA DELANTERA
Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
NEUMÁTICO TRASERO
Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, S1-S2: 27.5x2.3, S3- S6: 29x2.3"
CAMARAS
Standard, Presta valve
Product Details
DYNAMO
221395
Weight
DYNAMO
14.87kg (32 lb, 12.5 oz)
DYNAMO
S4
* Pesos basados en cuadros pintados de producción como se muestra en la imagen. Los pesos reales variarán en función del color, tamaño del cuadro y variación de componentes. Las especificaciones están sujetas a cambios sin previo aviso.
